This tool is non-stock and not returnable
Product Id: 23004720C
EDP: 90814
Sizes
| Diameter (DC) | 1.2mm |
|---|
| Diameter Dec | .0472 |
|---|
| Flute Length (APMX) | 4mm |
|---|
| Flute Length Dec | .1575 |
|---|
| Overall Length (OAL) | 38mm |
|---|
| Overall Length Dec | 1.4961 |
|---|
| Shank Diameter (DCONMS) | 3.175mm |
|---|
| Shank Diameter Dec | .1250 |
|---|
Specifications
| Coating | Uncoated |
|---|
| Country of Origin | USA |
|---|
| End Grind | Safe |
|---|
| Material | Carbide |
|---|
| NOF LH | 7 |
|---|
| NOF RH | 5 |
|---|
| PackageHeight | 0.2992 |
|---|
| PackageLength | 1.7992 |
|---|
| PackageWidth | 0.3937 |
|---|
| Shank Type | Straight |
|---|
| Tool Construction | Solid |
|---|
| Type of Cut | Down Cut |
|---|
| Weight | 0.00914331 |
|---|
