M.A.Ford® TuffCut® GP 4 Flute Ball Nose End Mill Stub 3mmx6x38 TiCN drawing M.A.Ford® TuffCut® GP 4 Flute Ball Nose End Mill Stub 3mmx6x38 TiCN drawing

Materials

  • Steel
  • Stainless steel
  • Cast iron
  • Non-Ferrous
  • Super-alloys and titanium
  • Hard material

Applications

  • High Efficiency Milling
  • Slotting
  • Traditional Roughing
  • Finishing
  • 3D Surfacing

M.A.Ford® TuffCut® GP 4 Flute Ball Nose End Mill Stub 3mmx6x38 TiCN

Product Id: 16511810C
EDP: 56566

Sizes

Diameter (DC)3mm
Diameter Dec.1181
Flute Length (APMX)6mm
Flute Length Dec.2362
Overall Length (OAL)38mm
Overall Length Dec1.4961
Shank Diameter (DCONMS)3mm
Shank Diameter Dec.1181

Specifications

Ball Radius Dec.0591
Ball Radius (RE)1.5mm
Center CuttingYes
CoatingTiCN
Country of OriginUSA
End GrindBall
Helix Angle30°
MaterialCarbide
NOF RH4
PackageHeight0.2992
PackageLength1.7992
PackageWidth0.3937
Shank TypeStraight
Tool ConstructionSolid
Trade NameTuffCut® GP
Type of CutRoughing/Finishing
Weight0.00874131
List Price: $28.34
Available: 6
